The Best 1325 CNC Marble Stone Engraving Machine for Price
☆This CNC marble engraving machine is also known as a CNC Granite engraving machine. It is mainly used for carving and engraving various stone materials. It has the advantages of a better cooling effect, fast engraving speed, and high engraving precision.
Stone Engraving Machines Video
Parameters
| Model | ELECNC1530S |
| X,Y axis travel | 1500x3000mm |
| Z axis travel | 200mm, option: 300mm, 400mm, 500mm, etc |
| Spindle type | 4.5kw water cooling spindle, ER25 |
| Inverter type | 5.5kw |
| Tool magazine | Not included |
| Tool holder with collet | ER25, collet: φ4, φ6, 1/8, 1/2 |
| Control system | DSP A11 handle controller, Option: NK105 |
| Driving system | Stepper motor FL118 bigger mode and Leadshine DM1182 option: Leadshine 750w Hybrid easy servo motor |
| Reducer | Not included, optional Japan Shimpo |
| Machine structure | Heavy duty body with quenching treatment |
| Work table | Aluminum T-slot & vacuum work table |
| Positioning cylinder | Option: 5 pieces (X2, Y3) |
| Linear guide | Taiwan linear guide, 25mm |
| Transmission | X,Y, Z axis: Taiwan TBI high precision ball screw |
| Lubrication system | 1.5L automatic lubrication system |
| Tool calibration | Easy tool sensor calibration |
| Cables | Germany Igus cables with CE, cUL certificate |
| Compatible software | Artcam, Alphcam, Type 3, Ucancam, Aspire, etc |
| Command language | G Code & M Code |
| Traveling speed | 30m/min |
| Working speed | 0-15m/min |
| Re-positioning accuracy | ±0.03mm |
| System resolution | ±0.0025mm |
| Working accuracy | ±0.03mm |
| Working air pressure | 0.6MPa |
| Working voltage | 220V 1PH/3PH 50HZ/60HZ 380V 3PH 50HZ/ 60HZ |
Features
- The heavy-duty machine structure ensures higher stability during stone carving, and the machine has a longer service life.
- Beginners are also very easy to use the control system.
- The effective table size of 1500x3000mm is enough to process large stone slabs.
Application
Stone CNC engraving machine is mainly designed for line carving, 2D plane carving, 3D relief, shadow carving, and other stone processing. It can process marble, granite, jade, crystal, tombstone, agate, ceramics, plastic, chemical composite board, and other materials. Widely used in processing marble and granite kitchen countertops, bathroom countertops, washbasins, tables, floor drains, etc.
