Best Large EPS CNC Router Price
☆The machine adopts high-quality four-row imported ball bearings, wide linear guide rails, and self-lubricating blocks. So it can ensure the precision and strength of the machine when engraving.
CNC Router Machines Video
features
- It has a 3000*50000mm super large work surface.
- Equipped with a number of high-end components.
- The 4th axis can be rotated ±90 degrees to realize 3D engraving.
Parameters
| Description | ELE-3050 | |
| Working size | 3000*5000*1000mm | |
| The 4th axis | ±90° | |
| Transmission | X /Y rack and pinion drive Z Taiwan TBI ball screw | |
| Table structure | Cast steel structure | |
| Spindle power | Italy 9kw HSD ATC air cooling spindle | |
| Spindle speed | 24000rpm | |
| Working speed | 20m/min | |
| Motor driver | 850w YASKAWA servo,1 kw YASKAWA servo driver | |
| Inverter | 11kw Taiwan Delta Inverter | |
| collet | BT40 | |
| Computer Interface | Ethernet | |
| Flash Memory | 256M(with CF card) | |
| Table Surface | Milling steel table(T-slot) | |
| Control System | Taiwan SYNTEC | |
| PS. All the working size and specifications can be customized according to your requests | ||
Application
Mold industry: It can be used in the precision production of various cast wood molds, and can also be used in the research and development and production of automotive interior and exhibition decoration materials.
Casting and sculpture industry: processing and engraving of various casting craft products, exhibition decoration materials, and GRG decoration materials. Building decoration industry: processing and production of building decoration materials such as GRG and GRC.
